Figure AI, founded by brothers Alex and Ihor Retviashvili following their tenure at OpenAI, has positioned itself in the commercial humanoid sector with a clear hardware-first mandate. The company’s Figure 01 and Figure 02 platforms are engineered for structured industrial environments, primarily warehouses and manufacturing floors. Unlike many competitors that lead with software demonstrations or rendered concepts, Figure AI’s evaluation must be graded by shipped hardware, verified pilot deployments, and published manufacturer specifications. This article applies that grading framework, separating documented engineering milestones from forward-looking announcements, and examines the realistic pathway for Indian industrial adoption.

Hardware Specifications & Mechanical Design

The mechanical architecture of Figure’s humanoids prioritizes joint density, weight distribution, and actuator response. Both generations share a common control philosophy but diverge in structural optimization and component sourcing.

Figure 01: Initial Deployment Platform

The Figure 01 serves as the company’s first production unit. Manufacturer documentation lists a height of approximately 5 feet 8 inches (173 cm) and a weight of 165 pounds (75 kg). The platform utilizes a combination of custom actuators and commercial joint modules, with a focus on torque density and thermal management. Battery capacity is rated for 2 to 4 hours of continuous operation under typical industrial loads. The Figure 01 shipped to BMW’s Spartanburg, South Carolina facility in 2023 for real-world testing, marking the company’s first hardware delivery milestone.

Figure 02: Updated Generation

Figure 02 represents a structural revision rather than a complete redesign. Key updates include a reduction in total weight to 140 pounds (63.5 kg), an increase to 28 degrees of freedom, and improved actuator packaging. The chassis utilizes lightweight composites and optimized aluminum framing to lower inertia during dynamic movements. Manufacturer spec sheets indicate enhanced wrist dexterity, faster step frequency, and refined proprioceptive feedback loops. The platform remains targeted at repetitive material handling, palletizing, and quality inspection tasks within controlled facility layouts.

Pilot Deployments & Shipping Milestones

Grading claims by shipping hardware first, Figure AI’s verified deployment history is limited but documented. The Figure 01 was delivered to BMW for testing at its Spartanburg plant, where it performed parts transport and assembly support under supervised conditions. Independent reporting from 2023 and 2024 confirms physical hardware on site, though performance metrics were not fully disclosed by either party. In 2024, Figure AI announced a manufacturing partnership with Fanuc to scale actuator production and assembly processes. While the collaboration indicates supply chain progress, independent verification of mass production volumes remains pending. All pilot deployments to date have occurred in highly structured, climate-controlled industrial environments, with safety personnel and remote override systems present.

Software Stack & Control Architecture

Figure’s control system relies on a closed-loop architecture that fuses vision-based localization, joint torque feedback, and gait planning. The company publishes limited technical documentation, but available whitepapers and demo footage indicate a modular stack that separates perception, planning, and actuation control. Vision models process depth and spatial data to navigate warehouse aisles and identify pick points. Proprioceptive sensors provide real-time joint position and load data, enabling dynamic balance correction. The software does not claim full autonomy; instead, it operates within predefined task trees with human-in-the-loop oversight for exception handling. Independent testing has shown stable navigation on flat, marked surfaces, with performance degrading on uneven terrain or unstructured clutter.

Manufacturing & Supply Chain Constraints

Humanoid assembly requires precision machining, custom actuator integration, and rigorous calibration. Figure AI’s partnership with Fanuc targets actuator scaling, but component lead times for high-torque motors, harmonic drives, and custom PCBs remain industry-wide constraints. Battery cells, power electronics, and thermal management systems must meet industrial safety standards before large-scale deployment. The company has not published full bill-of-materials or unit economics, which limits independent cost modeling. Scalability will depend on standardized joint modules, automated assembly lines, and supply chain localization for critical components.

India Market Context & Landed Cost Estimation

As of the current reporting period, Figure AI has not announced official distribution partners or pricing for India. Importing commercial humanoids into India requires compliance with Bureau of Indian Standards (BIS) certification, customs duty assessment, and GST registration. Robotics equipment typically faces a customs duty of 15% to 25%, plus 18% GST. Additional costs include freight, insurance, import clearance, and localized maintenance infrastructure. Based on industry benchmarks for comparable commercial humanoids, the approximate landed cost in India is estimated at ₹75 lakh to ₹1.2 crore per unit, depending on configuration, shipping terms, and duty classification. This estimate is clearly flagged as a projection and not an official Figure AI price. Indian manufacturers considering adoption must account for regulatory approval timelines, spare parts availability, and technician training requirements.

Operational Constraints & Independent Verification

Real-world deployment of Figure 01 and Figure 02 faces several documented constraints. Battery life remains limited to 2–4 hours, requiring shift-based charging or battery swapping protocols. Payload capacity is optimized for lightweight to medium loads, with manufacturer guidance recommending strict weight limits to preserve joint longevity. Environmental tolerances are defined for indoor use; dust, moisture, and extreme temperatures require additional enclosures or facility modifications. Maintenance cycles depend on actuator wear, sensor calibration, and software updates, which are not yet standardized across the industry. Independent verification of long-term reliability, mean time between failures, and total cost of ownership remains pending as pilot fleets expand.

Conclusion

Figure AI’s Figure 01 and Figure 02 represent a measured approach to commercial humanoid development, emphasizing shipped hardware and supervised industrial pilots over speculative demonstrations. The platforms show structural improvements in weight, joint density, and actuator integration, with verified deployments at BMW and manufacturing collaboration with Fanuc. However, scalability, supply chain localization, and long-term reliability data are still emerging. For Indian industrial adopters, regulatory compliance, import duties, and maintenance infrastructure will dictate near-term feasibility. Until independent fleet data and official pricing are published, the Figure series should be evaluated as an evolving hardware platform rather than a turnkey automation solution.
